Full-flat resistive touch screen
For beauty purpose，Vantouch provides the customized full-flat resistive touch screen.
This is a combination of aesthetic design, product quality and high cost-effective product, to enrich customization options.
In recent years, the full-flat resistive touch screen has become the mainstream of medical, automotive, commercial applications and man-machine interface devices.
Features of Vantoch 5 wire touch products
Structure: Decorative film (conductive)/ Conductive glass (FG) Decorative film/Conductive Film/Conductive glass (FFG) Size: 5.7~24.0 inches. Insurance: 3 year. Operation Life: > 35Million times Input mode: finger, glove, stylus Circuit grade: 3.3-5V DC, 35mA Contact jitter time: <2ms Transmittance: > 82% Operation temperature:-20~70℃ 20% ~ 80% RH Storage temperature:-30~80℃ 30% ~ 80% RH Surface hardness:3H. Surface coating: AG/AR
| Features of Vantouch 4 wire touch products Structure: Decorative film (conductive)/ Conductive glass (FG) Decorative film/Conductive Film/Conductive glass (FFG) Size: 3.5~15.6 inches. Insurance: 1 year. Operation Life: > 1Million times Input mode: finger, glove, stylus Circuit grade: 3.3-5V DC, 35mA Contact jitter time: <2ms Transmittance :> 82% Operation temperature:-20~70℃ 20% ~ 80% RH Storage temperature:-30~80℃ 30% ~ 80% RH Surface hardness:3H Surface coating: AG/AR Surface coating: AG/AR
|
Product applications
.Outdoor kiosk/ticket machine
.Cash register/game machine/industrial computer
.Medical devices/Car navigation
